Model | GD-15Y/3000 |
Double spindles/single power turret | |
Max turning diameter on the bed | Ф920mm |
Max processing length | 3000mm |
Max processing diameter(Disk type) | Ф630mm |
Max processing diameter(Cylindrical type) | Ф630mm |
Main spindle nose | A2-15(15”) |
Main spindle hole | Ф147mm |
Bar hole diameter | Ф135mm |
Main spindle speed | 1800rpm |
Main Spindle power | 37KW |
X/Z torque | 30 Nm |
Tool turret position | (BMT65)12pcs |
Turret model | BMT65 |
Tool size | 32x32mm |
Boring tool size | 50mm |
Driven head size | ER40mm |
Living tools milling speed | 4000rpm |
Axis rapid speed | 12m/min |
X axis travel | 325mm |
Y axis travel | ±60mm |
Z axis travel | 3300mm |
Processing accuracy | IT6 |
X ：≤0.003、Z：≤0.005 | |
Position accuracy | X ：≤0.008、Z：≤0.01 |
Tailstock travel | 3000mm |
Tailstock type | MT#6 |
Sleeve diameter | 150mm |
Sleeve travel | 150mm |
Machine weight | 13000KG |
Machine size | 6700*2400*2400mm |
Controller | Fanuc Oi-TF |
Model | GD-15Y/3000 |
Double spindles/single power turret | |
Max turning diameter on the bed | Ф920mm |
Max processing length | 3000mm |
Max processing diameter(Disk type) | Ф630mm |
Max processing diameter(Cylindrical type) | Ф630mm |
Main spindle nose | A2-15(15”) |
Main spindle hole | Ф147mm |
Bar hole diameter | Ф135mm |
Main spindle speed | 1800rpm |
Main Spindle power | 37KW |
X/Z torque | 30 Nm |
Tool turret position | (BMT65)12pcs |
Turret model | BMT65 |
Tool size | 32x32mm |
Boring tool size | 50mm |
Driven head size | ER40mm |
Living tools milling speed | 4000rpm |
Axis rapid speed | 12m/min |
X axis travel | 325mm |
Y axis travel | ±60mm |
Z axis travel | 3300mm |
Processing accuracy | IT6 |
Repeatability position accuracy | X ：≤0.003、Z：≤0.005 |
Position accuracy | X ：≤0.008、Z：≤0.01 |
Tailstock travel | 3000mm |
Tailstock type | MT#6 |
Sleeve diameter | 150mm |
Sleeve travel | 150mm |
Machine weight | 13000KG |
Machine size | 6700*2400*2400mm |
Controller | Fanuc Oi-TF |
